When designing modern ADAS and autonomous driving architectures, do you actually need a high channel count radar, or can software make up the difference?
To understand why channel count has become the defining metric of next-generation automotive radar, we have to look at how radar processes the world around it,
and why hardware boundaries ultimately dictate perception limits.
A radar’s virtual channel count is simple math:
{Transmit (Tx) Channels} x {Receive (Rx) Channels} = {Virtual Channels}
Each virtual channel provides an additional spatial observation of the environment. More channels give the radar finer data to determine exactly where reflections originate and to separate closely spaced objects.
| The Industry Benchmark: At Tech.AD Berlin, Dr. Jürgen Dickmann (former Head of Radar-Perception at Mercedes-Benz Group) stated that advanced ADAS radars require an array of no fewer than 32×32 channels (1,024 virtual channels) with a dense physical antenna to avoid inherent spatial ambiguity. |
In short: Software cannot interpret data the hardware never captured.
While machine learning can track objects over time and interpolate missing points, it relies on learned assumptions. In safety-critical edge cases, unfamiliar road debris, unusual vehicle profiles, or severe weather, relying on software to “guess” unmeasured spatial data introduces risk.
True safety redundancy requires hardware capable of capturing a high-resolution 3D picture natively in a single frame.
Historically, the bottleneck wasn’t the antenna, it was the processing power.
Processing thousands of virtual channels generates raw data workloads equivalent to ~3 Terabits per second. Legacy automotive processors simply couldn’t handle the compute, thermal, and power demands in a standard vehicle form factor.
Arbe solved this processing barrier by designing a dedicated chipset purpose-built for massive arrays, combining high-port-density RF chips with a custom radar processor to process 2,304 virtual channels in real time.
Vehicles built today will remain on the road for over a decade. As OEMs deploy Over-the-Air (OTA) updates to introduce higher levels of autonomy (Level 3 to full autonomy), those future software capabilities will always be constrained by the sensor hardware installed on the assembly line.
A high channel count radar provides the physical resolution, data density, and processing headroom required not just for today’s ADAS features, but for tomorrow’s autonomous capabilities.
