Why Sensor Fusion is Essential for L2+ and Higher Levels of Autonomy

And Why Arbe’s Perception Radar is Essential for Sensor Fusion

Autonomous driving is a complex task that requires reliable and accurate perception of the environment. While cameras are widely used in L2+ and higher levels of autonomous vehicles for their affordability and efficiency, relying solely on cameras for perception may not be enough to ensure truly safe autonomous driving and driver assist. For this reason, having two (or more!) different sensing technologies in a sensor suite is important, but combining the data from each can achieve even more. Sensor fusion is an approach to overcoming the limitations of individual sensors by integrating data from multiple sensor types. Fusing the information to run a unified perception algorithm on the merged data offers the most benefit and ultimate safety.

Cameras are Important, But Not Perfect

The camera is undoubtedly a foundational sensor for any autonomous sensor suite, providing visual information essential for perception tasks. Identifying the two dimensional shapes and colors of objects, for example, is crucial for reading lanes and pavement markings, and for classification, and is something cameras do exceptionally well. However, cameras also have certain limitations that make them fallible in certain scenarios.

For example, cameras may struggle with light saturation or white balance issues caused by changes in flows of light (think: the brightness of exiting a tunnel). The camera handles these scenarios by adjusting the shutter aperture, sometimes combined with algorithmic corrections. Still, the fact that cameras are not natively able to provide differentiation on the fringe between light and shade makes them vulnerable to false positives and false negatives.

Light saturation / white balance when exiting a tunnel

For the same reason, cameras struggle at night when a vehicle heading in the opposite direction forgets to turn down their high beams. The light saturates the camera’s image and, at some stage, the algorithm will have trouble discriminating objects on the road. This weakness is unfortunate at low speeds and close distances, but is even further exaggerated – and problematic – at high speeds and long range.

Another challenge for cameras is what is known as partial observability. Occasionally, a camera will have a line of sight but only to a part of an object – for instance, if a guardrail obscures the lower section of the vehicle. The camera can see the car, but it can’t see its true shape. This can lead to a false negative detection, although it is most often correctable with the algorithm. More often, partial observability creates depth perception challenges. Cameras can’t see depth immediately – they employ either stereoscopic mounting, sophisticated algorithms, or some latency between frames. While these corrective measures are usually effective, they are ultimately meant to overcome something that is basically a camera weakness or deficiency, and we can never be 100% confident that they alone are sufficient.

All of this is to say, cameras are clearly the basis for any automotive sensor suite, but they cannot and do not perform perfectly in every possible scenario. Only through sensor fusion – the combination of data from multiple sensor types – are we able to ensure both the data redundancy and the complementary strengths needed to achieve safety in every situation.

The Critical Benefits of Imaging Radar

To overcome the limitations of cameras and ensure reliable decision making, a versatile sensor suite is necessary. Leveraging different sensing technologies such as cameras, radars, lidars, and other sensors, improves the accuracy, robustness, and redundancy of detection results. Imaging radar has emerged as a key sensor for diverse sensing tech in the sensor suite to allow for truly safe L2+ to higher autonomy levels.

Imaging radar, like cameras, provides rich and detailed data about the environment, but with some distinct and complementary advantages. For example, imaging radar is capable of accurately detecting and tracking objects, even in challenging conditions such as low light, adverse weather, and partial visibility, and at greater distances, allowing for increased reaction time. Unlike cameras, imaging radar can also provide accurate distance and speed measurements thanks to the doppler effect that is available in radio frequency technology and not available in optic sensing. Imaging radar also resolves the challenge of an obscured line of sight; since radar RF signals wrap around objects, they are able to create a complete map of objects in the entire field of view. High resolution-radars are also capable of detecting, confirming, or correcting camera detections, and adding trajectory insights to those detections.

The inclusion of radar in the sensor suite very clearly improves object tracking – including inference of object distance, time to collision, and more – through data diversity, i.e. providing data that are unique to the radar.

Radar improving inference of object distance

Beyond this, only high-resolution imaging radar is detailed enough to provide data redundancy and be able to replace the camera if it is not available for any reason at levels sufficient to offer a complex application such as free space mapping. Overall, its complementary and supplementary nature with and for other sensors make imaging radar a critical component in the sensor suite.

Arbe’s Perception Radar is the First to Power Camera and High-Res Radar Fusion

Arbe’s Perception Radar, with its ultra high-resolution imaging, is a game-changer for sensor fusion with cameras. Given its exceptional angular resolution and frame registration, the high level of detail Arbe’s radar achieves, makes it possible to merge the two very different inputs from the camera and the radar.

The applications of the fused information are crucial for safety:

• Detection of objects or obstacles in challenging weather and challenging lighting conditions (in those cases the camera input may be limited)
• The dense input empowers reliable free space and object boundary mapping from both sensors.
• Detailed object data input, coupled with our AI algorithm, empowers object classification based on radar data
• High resolution in elevation allows the radar to accurately identify road incline – which is often missed by cameras and regular radars. This capability also supports decisions about “under-” and “over-drivability” (think: bridges and overpasses, for example), which is impossible with cameras alone.
• The lack of ambiguities from the perception radar means no computing power is wasted in trying to resolve them, and no contending with false alarms.
• Perception radar can detect a pedestrian at night, which might be too small for other radars, and which cameras cannot see in the dark.
• In fog or in a tunnel, the Perception radar can help detect stationary objects, such as an emergency vehicle parked on the side of the road. Traditional radars can’t pick up stationary objects, and cameras will struggle in low lighting conditions.
• Arbe’s radar is also beneficial in understanding the exact object boundaries for free space, even at night with oncoming high beams, allowing for safe and accurate driving.

Conclusion

A safe and successful vehicle sensor suite is not about competition between sensor types, but leveraging them to achieve the ideal combination. The more information each sensor type can provide – the higher the resolution and the denser the point cloud – the better and safer driver assist and autonomous driving will be.

By combining the strengths of different sensor types through fusion, vehicles can achieve a more comprehensive and reliable perception of the environment, which is critical for achieving true safety and real autonomy. Arbe’s Perception Radar is detailed and robust enough to support sensor fusion with cameras better than any other radar on the market, making it essential to ensuring accurate and reliable perception in all driving scenarios.

————————————
